Introduction for QT4-15 block making machine
Hawen QT4-15 Concrete block,paver making machine,with harmonic cooperation between mechanical, electrical and hydraulic machines functions, guarantee a reliable and stable production of different concrete products.
Customer can make various types of concrete products such as hollow block,interlocking paving stone,curb stone ,solid brick,solid block by changing the moulds.It is suitable for customer those who start the concrete making business with small investment.
Technical Specification for QT4-15 Automatic Block Making Machine | |
Pallet Size: | 980x560mm |
Vibration | Table Vibration |
Rating Pressure | 21Mpa |
Cycle time | 14-22s |
Motors Power: | 38KW For Main forming machine parts only with material conveyor belt |
Vibration motor | 2x7.5KW |
Machine Dimensions: | 8600x2300x2600mm |
Gross Weight: | About 7T |
Raw Materials: | crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes |
Applied Products: | concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, kerbstones, grass blocks, slope blocks, interlocking blocks, etc. |
Applied Fields: | widely used in buildings, road pavings, squares, gardens, landscaping, city constructions |
Installation power of plant | 60-70KW |
Capacity sheet for QT4-15 Automatic block making plant | ||||||
No. | Name | Dimension (mm) ( LxWxH) | Pictures | Number of block per Pallet | Block /1hour Estimated | Block /8hours Estimated |
1 | Hollow block | 400x200x200mm 8inch |
| 4 | 720 | 5,760 |
2 | Hollow block | 400x150x200mm 4inch |
| 6 | 1,080 | 8,640 |
3 | Solid brick | 230x110x75mm |
| 14 | 3,360 | 26,880 |
4 | Square shape paver | 250x250x60mm |
| 6 | 1,080 | 8,640 |
5 | Zigzag Paver | 200x100x60mm |
| 16 | 2,800 | 22,400 |
6 | Rectangular Paver | 200x100x60mm |
| 16 | 2,800 | 22,400 |
More information,please contact our sales team:export@hwmachines.com
